| Power | USB, or +7 V to +28 VDC via D-SUB (nominal ~12 VDC), protected against overvoltage, reverse battery, ESD and transients |
|---|---|
| CAN channels | 2 independent channels |
| Protocols | CAN 2.0A, CAN 2.0B and CAN FD (ISO 11898-1) |
| Max bit rate | 1,000 kbit/s arbitration; 10,000 kbit/s CAN FD data phase |
| Timestamp resolution | 1 microsecond |
| Receive buffer | 1,000,000 message ring buffer |
| Bus termination | Channel Independent software configurable |
| Connectors | Male + female pass-through DB9 on channel A, CiA® 106 pinout |
| Listen-only mode | Yes (silent mode) |
| Standalone sending | Yes, without a PC connected |
| DBC decoding | Yes (ARXML scheduled) |
| Log file formats | ASC, BLF and TRC imports plus native SLSS formats |
| Interfaces | TCP/IP, documented API, J2534 pass-thru 04.04 with CAN 2.0 and CAN FD |
| Data display | Hex, decimal and binary plus ASCII in parallel |
| Operating temperature | −40 °C to +85 °C |
| Enclosure | IP40 plastic |
| Protection | ESD, overvoltage and transient protection |
| Software included | Lifetime SLSS CANAnalyser licence, no subscription |
| Hardware logging | Micro-SD card slot, logs with no PC attached |
| Bus playback | Play recorded logs back onto either channel |
| GPIO | 2 inputs and 2 outputs, automotive grade |
| GPIO input protection | −28 VDC to +28 VDC |
| GPIO output drive | Up to 14 mA steady state at CMOS levels (0 V / 5 V), overvoltage protected to 28 VDC |
| GPIO safety | Short-circuit protection on all pins; thermal shutdown on the regulator |
| Peripherals | Qwiic connector access |
| Triggered capture | CAN message triggered event |
| Price | $495.00 MSRP |
The Lab CAN Pro module encapsulates all the previous features of the Desk CAN pro and adds advanced features with robust hardware data storage on its built-in 8 GB micro-SD card, GPIO interface for real world logic interface and gateway capability as well as the qwiic interface for peripheral access and the direct interface capabilities to the Flextech Bus Monitor tool for A2B logging in parallel with CAN, making it the ultimate tool for high-speed logging, real bus playback, and seamless peripheral integration. Tailored for demanding applications, it delivers flexibility and performance in one compact package.
With high-speed hardware logging, it enables the efficient capture of large volumes of data without the need for being connected to a PC, ensuring reliable and fast performance in even the most challenging environments. For robust and portable data storage, the integrated micro-SD card slot allows logging directly onto a card, making it ideal for disconnected scenarios.
Some of its standout features are real bus playback, which provides the ability to replay recorded data with precision, enabling thorough analysis and testing of communication streams. Additionally, the dongles can operate as standalone gateways, capable of processing and transmitting data between networks without the need for a host device.
For system expansion, the qwiic-compatible connector allows the seamless integration of peripherals such as sensors and displays and the only tool capable of parallel CAN + A2B chronological logging when mated together to the FlexTech A2B Bus Monitor, unlocking additional functionality.
Lab CAN Pro works with SLSS CANAnalyser for DBC decoding, logging and automation over its TCP/IP API. Compare it with the entry-level Desk CAN Pro in the technical specifications, or download the datasheets. Like every SeRoSys tool, Lab CAN Pro supports CAN 2.0 and CAN FD as described in the CAN bus standard and is a one-time purchase with no recurring license fees.
